Quick Details

  • Condition: New
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: GEMCO
  • Model Number: ZLSP-D 230A chicken feed pellet machine.
  • Type: Feed Pellet Machine
  • Voltage: 220V/380V
  • Power(W): 22Hp
  • Dimension(L*W*H): 1560x580x1000mm
  • Weight: 310 kg
  • Certification: ISO, BV and CE Certificated chicken feed pellet machine
  • Warranty: 1 Year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Application: pelletizing maize ,soybean meal , etc.
  • Usage: make feeds for chicken , cattle , pig,etc.
  • Raw material: Grains Powder
  • Pellet output: 120-200kg/h
  • Pellet diameter: 4-12mm
  • Motor choice: Electric and diesel, PTO , Gasoline
  • Electri-starter: Be equiped
  • Product Name: catfish feed pellet machine
  • Pellet Forming Rate: >90%
  • Powder Rate: <10%

Packaging & Delivery

Packaging Details All our animal feed pellet making machines are packaged seriously with strong frame and wood cases to ensure you get the feed pellet machine in perfect state Besides, if you have any other requirement on the anmial feed pellet machine package, don't hesitate to contact us And we will do our best to meet your demand.
Delivery Time 15 days after receiving prepayment

Wholesale price homemade diesel small capacity catfish pig rabbit poultry chicken feed pellet machine for sale

The chicken feed pellet machine can process the oil cake and other mixed waste material to granule at one time. The poultry feed pellet machine is drived by electric motor, diesel engine, PTO or gasoline engine. To make final Pellet diameter: 2.5-8mm.



Small Flat Die chicken feed pellet machine technical parameters

ModelPowerCapacity (kg/h)G.W./N.W.Packing Size
ZLSP-D 120A8 Hp60-100120/140900x500x730
ZLSP-D 150A8 Hp90-120180/2201000x500x750
ZLSP-D 200A15 Hp200-300210/2401460x750x900
ZLSP-D 230A22 Hp300-400280/3101560x850x1000
ZLSP-D 260A30 Hp400-600330/3601200x500x1070
ZLSP-D 300A55 Hp600-800410/4501220x600x1000

Raw Material and Finished Pellets for poultry feed pellet machine

The chicken feed pellet machine is mainly used for making animal feed pellets. Raw material can be corn, bean pulp, straw, grass, rice husk, oil cale, etc.

The size of catfish feed pellet machine has various choices: 2.5-10mm, or other customized diameter. At the same time, you can customize the flat die of the poultry feed pellet machine with different thickness and compression ratio to adapt to different materials and realize best pelleting result.

What features does our flat die small chicken feed pellet machine have?

Easy to operate and clean, only 1 or 2 workers are OK.
Spare parts are easy to change, less cost for rollers and dies
The pelletizing process is visible, so it is convenient to solve problems in time.
Driven by diesel engine and motor,this diesel flat die pellet mill can be used in nearly everywhere in the world, especially popular for areas with shortage supply of electricity.
Diesel flat die pellet mill has compact structure and light weight which enable it to be moved freely and more adjustable to small pellet production.
Equipped with high quality alloy steel roller and die by advanced craft. The visibility desugn of the pelletizing chamber ensures a smooth pelletizing process and timely repairing.
Feed and grass meal can be directly made into pellet without adding any liquid materials. The pellets size various from dia 2.5mm, 3mm, 4mm, 6mm to 8mm for different kinds of animals

High quality chicken feed pellet machine spare parts

Precise catfish feed pellet machine spare parts processing

GEMCO poultry feed pellet machine Honor

GEMCO Energy is a member of CAREI (China Association of Rural Energy Industry) and China Flat Die Biomass Animal Poultry Chicken Catfish Feed Pellet machine Forming Technology Standards Formulating Group. It is also ISO9000 and CE qualified (by SGS). Now GEMCO has obtained 8 national patents, and become one of China Export Customs Class A enterprises.

Q&A of chicken feed pellet machine

This is my first time to import, how can I trust your company and ensure to get the goods if I order from you?Q:
We are alibaba legitimate certification company (VIP), and we support payment terms: L/C. Escrow, to ensure your safety.A:


There are too many models, i don't know which one to choose.
Welcome to contact us through TradeManager,we will recommend according to your requirement. If during closing time or weekend, Please send mail to us,we will response within 24 hours.


How to ensure that I received the machine undamaged?
At first , our package is standard for shipping, before sign in, please cfm product undamage, otherwse, pls contact with us within 2days, we've bought insurance for you, we or shipping company will be responsible!


How do we pack the poultry feed pellet machine?


catfish feed pellet machine in complete feed pellet plant

Click Now for Catalogs & Factory Price!

Why our poultry feed pellet machine cost less?

The chicken feed pellet machine customer visits
