Quick Details

  • Condition: New
  • Place of Origin: Henan, China (Mainland)
  • Brand Name: GEMCO
  • Model Number: ZLSP-D 230B pelletizing machine
  • Voltage: 380V
  • Power(W): 3phase 11kw
  • Dimension(L*W*H): 1180*540*1000
  • Weight: 290/320kg
  • Certification: ISO, CE
  • Warranty: 1 Year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Power: Motor of laboratory pelletizing
  • Authentication: ISO.CE for all pelletizing machine
  • Capacity: 120-200 kg/h of pelletizing machinery
  • Other: Environment Protection
  • Use: Woodworking
  • Color: As Customer's Need
  • Pelletizing: For Fuel
  • Packing: Plywood Case
  • High quality 100% wood pellet biofuels: OEM Production
  • name: pelletizing machinery

Packaging & Delivery

Packaging Details: All pelletizing machine are packed with plywood case, also can be packed as your requirement
Delivery Detail: 7-15 Days after receive the prepayment

Cheap small mini wood pelletizing extruder machine line designed laboratory pelletizing machinery


With the fast development of biomass energy saving project, this kind of flat die pelletizing machine become very popular. Since it has changed to process the waste biomass materials and agriculture wastes to wood pellet. This cheap small mini wood pelletizing machine has a history for more than 10 years. We manufactures this pelletizing machinery. GEMCO pelletizing machine is mainly used for small-scale wood pellets production for home heating, animal bedding plant, etc. The final wood pellet can be burned as green fuel in pellet stove or boiler.

Today, 2017 hot wholsesale homemade wood pelletizing machine is our flat die ZLSP series portable pelletizing machine.

Parameters of pelletizing machine

Flat die pelletizing equipment is designed into two types which are fixed mold with turning roller(R-Type) and turning mold with fixed roller(D-Type) .

D-Type pelletizing machine
ModelPower(kw)Output(kg/h)Weight(kg)Packing Size(mm)
ZLSP-D 150B3phase 5.550-10095/110800*450*700
ZLSP-D 200B3phase 7.580-120200/2301050*480*930
ZLSP-D 230B3phase 11120-200290/3201180*540*1000
ZLSP-D 260B3phase 15160-250320/3601240*540*950
ZLSP-D 300B3phase 22250-400350/3801300*560*1100
ModelPower(kw)Output(kg/h)Weight(kg)Packing Size(mm)
ZLSP-D 150C3phase 5.560-110105/1251000*480*780
ZLSP-D 200C3phase 7.580-120210/2301050*550*830
ZLSP-D 230C3phase 11120-200290/3201200*560*950
ZLSP-D 260C3phase 15160-250340/3701240*580*1000
ZLSP-D 300C3phase 22250-400425/4651300*620*1100

For hardwood pelletizing machinery, we choose the fixed mold with rotating roller for its large pressure.

R-Type pelletizing machine
ModelPower(kw)Output(kg/h)Weight(kg)Packing Size(mm)
ZLSP-R 200B3phase 7.580-120215/245950*450*1050
ZLSP-R 300B3phase 22250-350540/5751350*750*1400
ZLSP-R 400B3phase 30350-450770/8101400*800*1450
ZLSP-R 420B3phase 37400-6001100/12001630*620*1400
ZLSP-R 550B3phase 55500-80017702300x750x1850

Click Now for Catalogs & Factory Price!

Cheap wood pelletizing machine

Features of flat die pelletizing machine

1.The whole machine adopts special high quality materials; the gear parts is made of superior alloy steel and wear-resistant materials; thus has long 2.working life.
3.The speed of flat die and rollers can be adjusted precisely by the transmission of gear box for pressing superior pellets; visible pelletizing process, easy to operate.
4.Uniform pressing, high density and heating capacity wood pellets, with diameter changeable from 6mm-12mm.
5.Versatile in pressing different materials like sawdust, wheat straw, branch, bamboo, paper, palm kernel shell, fiber waste, etc. The pelletizing machine has the characteristics of green-envrionment, lower-enenrgy, and cheaper larbor.
6.Small and light in weight, can be fixed in a plant or movable in a vehicle, thus available to residential or farm wood pellet making.

Click Now for Catalogs & Factory Price!

Working principle of pelletizing machine

Flat die pelletizing machine is operated through gear driving the spindle and die. Designed in vertical type, raw materials fall down from the hopper into pelletizing chamber smoothly just because of gravity. In pelletizing chamber, wood materials are compressed into pellets between rollers and die through die holes. A sharp cutter would immediately cut the exposed pellets into regular length. The relatively low rotary speed can ensure pellets’ integrity.



Click Now for Catalogs & Factory Price!

Characteristics of GEMCO pelletizing machine

  • The flat die pelletizing machine has scientific and reasonable structure covering small area. It also has low noise.

  • With the high productivity and low energy consumption (compared with industry average) in the wood pelletizing machinery.

  • This  GEMCO portable pelletizing machinery has high pellet forming rate. The pellets made by this flat die laboratory pelletizing have high hardness, smooth surface and easy to store and transport.

  • For making biomass pellets as fuel, GEMCO cheap pelletizing machine has various die holes ranging from Ø6- Ø10 to meet your requirement. The compression ratio (which determines the forming effect of pellets) of the die hole is designed in accordance with your raw material in order to realize the best pelletizing result.

  • The flat die homemade wood pelletizing mills easy to operate and maintain with excellent safety.

  • It can be used in any places: in the farm, near your field, at home, in the workshop, etc.



Click Now for Catalogs & Factory Price!

Why choose GEMCO pelletizing machinery

1. The simple design of the pelletizing machinery are quite less space-consuming than ring die pelletizing machinery. These small pelletizing machinery could be transported conveniently and much more flexible to smaller scale pellets production plant.
2. Pelletizing process is visibility for flat die pelletizing equipment. By viewing entire process within the chamber you'll discover precisely what the genuine trouble is and solve it quickly whenever problems happen.
3. Flat die pelletizing machinery can either be powered with an electric motor or diesel engine. You can have a free choice according to your local condition. If you’re going to choose electric pelletizing machinery, make sure you have enough power capacity in the pelletizing location. Besides, make sure you take the costs of upgrading your electrical system into consideration. Even though it is a one time cost, it will still affect your return on investment.



Click Now for Catalogs & Factory Price!

Certifications


Click Now for Catalogs & Factory Price!

Packing & delivery & customer

Click Now for Catalogs & Factory Price!

Click Now for Catalogs & Factory Price!

For more details, Pls contact me.
